Main Specifications:
- Available wavelength: 808nm
- Size: Φ45mm×100mm
- Output power: 100mW
- Output aperture: dia.6mm
- Operating voltage: DC 3V
- Operating current: less than 250mA
- Standard operating distance: 10 meters focus adjustable
- Beam character: elliptical
- Elliptic proportion: more than 1:2
- Beam size: about 4mm x 400mm @10 meters
- Divergence: 0.3mrad
- Optics: glass lens both sides AR coated
- Operating temperature: -10-+40 Celsius degree
- Storage temperature: -40-+80 Celsius degree
- Life time: more than 8000 hours
- Laser safety classification: class 3
