Product> 520nm



CE520-5-5(16x55)

Main Specifications:

  • Available wavelength: 520nm
  • Siae: dia.24mm x len.96mm
  • Output power: 2mW
  • Output aperture: dia.20mm
  • Operating voltage: DC 3V
  • Operating current: less than 60mA
  • Standard operating distance: 50 meters
  • Beam character: roundish but brightness not uniform
  • Elliptic proportion: 1:1
  • Divergence: 0.2mrad-0.4mrad
  • Optics: glass lens both sides AR coated or Plastic lens
  • Operating temperature: -10-+40 Celsius degree
  • Storage temperature: -40-+80 Celsius degree
  • Life time: more than 8000 hours
  • Laser safety classification: class 2
  •
